SP Series
Bar Diameter ø2.0mm～ø20mm
Double-layer bar loading increases loading capacity.
Available for end trimming and various profiled bar feeding devices.
Movable stands facilitate replacement and maintenance.
Synchronization device can be moved together with the spindle of sliding headstock lathe.This reduces feeding pressure on the bar.
Pneumatic anti-vibration device provides an outstanding anti-vibration and reduces noise.
| Model | SP 212 | SP 315 | SP 520 |
| Bar Diameter | ⇥●⇤ Ø2mm~12mm | ⇥●⇤ Ø3mm~16mm | ⇥●⇤ Ø5mm~20mm |
| Bar Loading Capacity | Ø6mm x 70(支) | Ø6mm x 70(支) | Ø6mm x 70(支) |
| Power Supply | 220/440VAC 50/60HZ | 220/440VAC 50/60HZ | 220/440VAC 50/60HZ |
| 型號 | 25 | 30 |
|---|---|---|
| L | 3660~4340 | 4165~4840 |
| A | 2580 | 3080 |
| B | 1880 | 2380 |
| C | 2580 | 3080 |
| Weight | 180KG | 190KG |
Recommend
NB Series
Bar Diameter ø 0.6mm～ø7mm
The bar feeder is especially ideal for small precision parts, such as watch parts, electronic parts and so on.
Double clamping device provides positively material clamping and releasing.
Spiral workpiece infeed system requires no further adjustment when changing bar sizes.
Heavy weight feeding system increases stability of feeding.
